300W Portable Dot Peen Marking Machine For Circular Surface Marking

China 300W Portable Dot Peen Marking Machine For Circular Surface Marking supplier

Large Image :  300W Portable Dot Peen Marking Machine For Circular Surface Marking

Product Details:

Place of Origin: China(mainland)
Brand Name: CHUKE
Certification: FDA,ISO,CE
Model Number: PMK-G01

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: USD 1300-1600 per set
Packaging Details: Packing in carton,45*45*55cm
Delivery Time: after payment 7-15 working days
Payment Terms: L/C, D/A, D/P, T/T, , MoneyGram
Supply Ability: 600 sets per month
Contact Now
Detailed Product Description
Apply Material: Aluminum Alloy Material Marking Contents: Alphanumeric Info,Data Matix Or Dot Matrix 2D Codes,shift Codes,barcode,serial Number,date,VIN Code,date,letter,figure,logo,graphics And Etc.
Service: Good Aftersales Service Controller: 7"LCD Touch Screen
Marking Directions: Horizontal,gradient,flat,circular Arc Surface Product Name: 300W Portable Dot Peen Marking Machine For Sale Circular Surface Marking
Marking Area: 140*80mm Marking Materials: Normal Below HRC60,Hard Material Below HRC90.
Compressed Air: 0.2-0.6Mpa Voltage: 110V/220V
High Light:

dot peen engraving machine

,

portable dot peen marker

300W Portable Dot Peen Marking Machine For Sale Circular Surface Marking


Principle:


The computer controlled printing needle moves in a two-dimensional plane of X and Y. At the same time, the printing needle is subjected to high frequency impact motion under the action of compressed air, so as to print beautiful marks on the workpiece.


Application:

Handheld series pneumatic marking printers (special products in the general series of marking machines). It is specially printed for printing of unsuitable objects, such as large valves, frame number, and processing materials.300W Portable Dot Peen Marking Machine For Circular Surface Marking
Portable Dot Peen Marking Machine parameter

model Pneumatic marking machine
weight 20kg
Machinpower <300w
Power supply 220v/110v
Strokefre quency 300times/s
Marking speed 2-5 characters(2x2mm)/s
Marking depth 0.01 to 1mm (Vary to the material)
Standard marking area 80x40mm,130x30mm,140x80mm,200x200mm



Usage method


 Control box power indicator light
1, please confirm whether the power supply line of the control box is connected well.
2. Please confirm that the power switch of the control box is open.
3. Please check whether the fan works on the rear panel of the control box. If it is not working, check the fuse (2A) on the rear panel to fuse and replace.
If the work, please open the control box, check the control panel on the insurance tube (6A) and power fuse replacement;
4. Open the control box after the replacement of the insurance. If the insurance is still fusing, please check whether the drive in the control box is damaged. If the damage is found, remove it, replace the insurance on the control board, open the control box, and observe whether the insurance is fusing, such as non fusion, and the replacement of the drive.


Product features


 Portable pneumatic marking machine, it inherits the advantages of desktop pneumatic marking machine original, made a great improvement in the applicability of the products, to make up for the lack of desktop, marking machine easy to use, simple operation, easy to carry, and with the use of single-chip computer or notebook.



FAQ

Do you have more people to buy your marking needles?
This is a very good question. Of the 10 national marking machines, 7 of them are used as our marking needles. Do you think there are very few people who buy our marking needles? "


Design feature

The serial number: high automation programs can be automatically extended print printer, without manual input, thereby reducing the manual operation error,
At the same time, it can also improve the work efficiency of product marking.


Function

The special symbols of the match are:  pentagram, rice
The graphics are customized according to the needs of the user.


After service

Free training for Software operation and setting.

Packing and shipping
Packing by wooden case, packing size :45*45*55cm more security delivery with heavier weight and higher freight

Delviery time 7-15 working days
Type of shipping Express,air or sea
Terms of payment T/T,credit card,,paypal
package size 45*45*55cm
Gross weight 22KG



Chuke Factory
Chongqing CHUKE intelligent machinery equipment Co., Ltd. was founded in 2006, before our staff has many years of experience in machining, so our company is established in the initial marking needle production business, with the needs of customers, our company gradually realize the business expansion to the technical force so far the company has domestic counterparts in the forefront custom business, reached a new height, either pneumatic marking machine or laser marking machine has been recognized by customers, the marking needle is occupied most of the domestic market market. Our products have been certified by world - known quality systems, including ISO, CE, PDA, TUV and so on. Recently, the company is tackling new technical problems to provide new services to customers with higher requirements. Our products are implemented within the warranty period for free repair and replacement of the shelf life, only charge the cost of fees, inventory at any time to solve customer as pressing danger to address customer needs, for the purpose of. No matter where you are, we can serve you. was founded in 2006, before our staff has many years of experience in machining, so our company is established in the initial marking needle production business, with the needs of customers, our company gradually realize the business expansion to the technical force so far the company has domestic counterparts in the forefront custom business, reached a new height, either pneumatic marking machine or laser marking machine has been recognized by customers, the marking needle is occupied most of the domestic market market. Our products have been certified by world - known quality systems, including ISO, CE, PDA, TUV and so on. Recently, the company is tackling new technical problems to provide new services to customers with higher requirements. Our products are implemented within the warranty period for free repair and replacement of the shelf life, only charge the cost of fees, inventory at any time to solve customer as pressing danger to address customer needs, for the purpose of. No matter where you are, we can serve you.
