Product Details:
Payment & Shipping Terms:
|
| Colour: | White | Maximun Speed: | 7000mm/s |
|---|---|---|---|
| Laser Brand: | MAX | Application: | Mould |
| Application Material: | Steel, All Kinds Of Metal Materials | Marking Depth: | 0.01-1mm |
| Service: | Can Customize | Support Graphics Formates: | Company Name/logo |
| High Light: | industrial laser marking equipment,laser marking device |
||
Working principle
The metal laser marking machine uses the laser beam to mark on different metal materials surface. The marking effect is to evaporate the surface materials, then here will show out the deep materials. Or using the light’s feature of changing the physics and chemical reflection to mark on metal surface. Or it is to use the light to burn the part materials, then it will also shows the pictures, letters accordingly.Heating processing is the laser beam with high energy density. (It is the high centralized energy flow) . When it reflects to the marking materials, then the marking materials can absorb the laser energy. In the laser lighting area, it will inspire the laser radiation. It will enhance the marking materials surface’s temperature due to the allergic, burning, and evaporation.
|
Laser power |
10W/20/30/50W |
| Laser Wavelength | 1064nm |
| Light beam quality | <2 |
| Repeating precision | ±0.002 |
| Marking range | 110x110mm(customize) |
| Marking depth | 0.01~1mm |
| Marking speed | 7000mm/s |
| Minimum character | 0.15mm |
| Minimum line width | 0.01mm |
| Repeating frequency | 20KHz~30KHz |
| Marking content |
Graphics, text, bar codes, two-dimensional code, date, batch number, serial number |
| Graphic format supported | bmp,png,ai,dxf,dst,plt |
|
|
220V±10%/50Hz/4A |
| Size | 570mmx270mmx200mm |
| Gross Weight | 135kg |
| Control interface | standard USB port |
| Laser module life | 100000~200000 hours |
Application
Aluminium mini laser can be a variety of single dot matrix and vector font to print, print letters, numbers, symbols, icons, Chinese characters, one-dimensional bar codes, two-dimensional bar code, serial number, date and time, random number, real time variable logos and other words.
Before using the laser marking machine, we must first understand their structure, then use the machine to turn on and turn off the machine. The order is also not disorderly. First, turn on the power, then open the dust-proof cover of the laser, and then turn off the dust-proof hood when he uses it, and turn off the power.
1. Non-contact processing, tool-free wear and tear, do not need to change tools, positioning design easier.
2. The laser beam is easy to guide, focus to achieve for all directions, easy to coordinate with the CNC system for processing complex parts.
3. Can be high hardness, high brittleness, high melting point and soft materials for processing. The company is located in:
4. Laser beam high energy density, processing speed, the workpiece deformation is small, heat-affected zone is small, follow-up processing small. The company is located in:
5. Easy to combine with the traditional production process to form a production line.
Purple Asahi fiber laser marking machine configuration covers 10W, 20W, 30W, 50W all models, is your purchase of a new generation of laser equipment of choice! Mini laser marking, ultra-small size, light weight, easy to carry, is your best choice
.
FAQ
1.Is the type of laser radiation visible, invisible or colored?
It is white colored
2.If the color then adjusts the color of the laser and in what ways automatically with the software or in the manual?
It is automatically with the software
Design feature
The role of the focusing system is to focus a parallel laser beam at a point. Mainly using f- theta lens, different focal length of f- theta lens is different, marking effect and range are also different. Fiber laser marking machine selects imported high-performance focusing system, its standard lens f=160mm is focal length, and the effective scanning range is 110mm. The user can choose the type of lens according to the needs.
The optional F- theta lens has:
F=100mm, the effective focus range is 65mm.
F=160mm, effective focusing range of 110mm.
Packing and shipping
The normal package is wooden box(Size: L*W*H),It also changes from the size of machine ,We can delivery the machine by express,air or by sea
Aftersale service
3 year guarantee period for product quality. (man made damaged is negotiable).
Lifelong maintenance and spare parts supply.
Free training for machines installation and operation of the staf
payment terms
Chuke Factory
Chongqing Chuke Intelligent Machinery &Equipment Co.,Ltd is a professional manufacturer for industrial laser equipment. Since 2006, chuke is specializing in the production of fiber laser marking machine, CO2 laser marking machine, portable laser marking machine and so on, widely used in electronics, pcb, metal,copper, aluminum, hardware, model-making, clothing, footwear, advertising, printing and packag
ing, toy-making, as well as more industries.
