High Precision Laser Engraving Machine For Wood Beam circularity >90

China High Precision Laser Engraving Machine For Wood Beam circularity >90 supplier

Large Image :  High Precision Laser Engraving Machine For Wood Beam circularity >90

Product Details:

Place of Origin: China(mainland)
Brand Name: ZIXU
Certification: CE,FDA,ISO
Model Number: ULMM-A01

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: USD 10000-15000 per set
Packaging Details: Packing in wooden case,95*81*122cm
Delivery Time: after payment 7-15 working days
Payment Terms: L/C, D/A, D/P, T/T, , MoneyGram,Paypal
Supply Ability: 500 sets per month
Contact Now
Detailed Product Description
Laser System Language: English Feature: High Precision
Machine Structure: Desktop Type Material: Wood
Service: Free Sample Marking Laser Power: 3w
High Light:

uv laser marker

,

uv laser engraving machine

High Precision Good Quality Wood Uv Lasers For Sale





Product introduction



The effect of marking is directly interrupting the molecular chain of matter (short wavelength laser), which is different from the evaporation of deep surface material produced by long wave laser, revealing the etched pattern and text.



Parameter
Parameter index
Unit
Illustration
Laser wavelength
354.7
nm
/
Average output power
3.0-5.0
W
@30kHz
pulse width
<20
ns
@30kHz
Pulse repetition frequency
10-100
KHz
/
Laser output mode
TEM00
/
/
Beam quality
<1.2
/
/
Spot diameter
0.8+-0.1
mm
Measured at window
Beam divergence angle
<1.2
mrad
/
Beam circularity
>90
/
/
Pulse stability
<3
%
RMS/@30kHz
Power stability
<5
%
RMS/8hr
Beam pointing stability
<30
urad/℃
/
Polarization degree
>100:1
/
/
Polarization direction
Horizontal
/
/
Working temperature and humidity
10to35 <80
℃ %
/
Storage temperature and humidity
-20 to 65 <90
℃ %
/
Power
100-240 50/60<500
VAC Hz W
Single phase
Warranty
15
months
/



Samples
High Precision Laser Engraving Machine For Wood Beam circularity >90


Application
Especially in the high-end market of ultra fine processing, the surface of the packaging bottle of cosmetics, medicine, food and other polymer materials, flexible PCB board marking



Usage method
The equipment is clean and lubricated.
There are no sundries on and around the equipment
The current of the equipment is not easy to exceed 20A
A cell phone, a strong magnetic object, or not close to the mirror



Product features

UV laser can achieve hyper fine marking and special material marking because of its small focus spot and small heat affected zone. It is the preferred product for customers to have higher requirements for marking.





FAQ



The common fuse is broken, or the circuit is open. The inspection is measured by a multimeter. Handle: replace the fuse, or connect the circuit.





Design feature

UV laser marking machine is based on its unique small power laser beam





Product features



In addition to copper material, UV laser is more suitable for processing. Not only good beam quality, smaller focused spot, the realization of ultra fine marking; more extensive scope of application; minimal heat affected zone, will not produce thermal effects, does not produce material burning; high efficiency; marking speed, stable performance, small volume, low power consumption advantages.







Chuke Factory



Chongqing chuke  intelligent machinery equipment Co., Ltd. was founded in 2006, before our staff has many years of experience in machining, so our company is established in the initial marking needle production business, with the needs of customers, our company gradually realize the business expansion to the technical force so far the company has domestic counterparts in the forefront custom business, reached a new height, either pneumatic marking machine or laser marking machine has been recognized by customers, the marking needle is occupied most of the domestic market market. Our products have been certified by world - known quality systems, including ISO, CE, PDA, TUV and so on. Recently, the company is tackling new technical problems to provide new services to customers with higher requirements. Our products are implemented within the warranty period for free repair and replacement of the shelf life, only charge the cost of fees, inventory at any time to solve customer as pressing danger to address customer needs, for the purpose of. No matter where you are, we can serve you. was founded in 2006, before our staff has many years of experience in machining, so our company is established in the initial marking needle production business, with the needs of customers, our company gradually realize the business expansion to the technical force so far the company has domestic counterparts in the forefront custom business, reached a new height, either pneumatic marking machine or laser marking machine has been recognized by customers, the marking needle is occupied most of the domestic market market. Our products have been certified by world - known quality systems, including ISO, CE, PDA, TUV and so on. Recently, the company is tackling new technical problems to provide new services to customers with higher requirements. Our products are implemented within the warranty period for free repair and replacement of the shelf life, only charge the cost of fees, inventory at any time to solve customer as pressing danger to address customer needs, for the purpose of. No matter where you are, we can serve you.





Packing and shipping



Packing by wooden case, packing size,for desktop model:95*80*122cm,more security delivery with heavier weight and higher freight





Delviery time 7-15 working days
Type of shipping Express,air or sea
Terms of payment T/T,credit card,,paypal
package size 95x81x122cm
Gross weight 188KG
