| Name: | Stainless Steel Shower Fiber Welding Machine | New: | Yes |
|---|---|---|---|
| CNC: | Yes | Color: | Customized |
| Customized: | Yes | Ctystal: | ND:YAG |
| High Light: | stainless steel welding equipment,fiber optic welding machine |
||
Cost of Laser Welding Machines for Sale Stainless Steel Metal Welder Alternative
Stainless Steel Metal Laser Welding Machine Description
Stainless steel showers are shower heads and are common in bathrooms. The general sanitary ware manufacturers use the traditional welding process, but the high-end shower products are now gradually adopting the laser welding process.
First of all, the laser welding has little thermal effect, and the metallographic phase of the product will not be changed after welding, without blackening, discoloration, deformation, etc. Phenomenon;
Secondly, laser welding efficiency is high, easy to achieve automation, welding efficiency can reach 2-5 times of traditional welding process.
In short, the laser welding quality is good, the sealing is strong, and the weld seam is silver-white after welding, which can be simply polished.
Stainless Steel Metal Laser Welding Machine Application
Bathroom shower laser welding machine can be used for most metal materials: welding of aluminum, stainless steel, gold, silver, alloy, steel, diamond equivalent or welding of dissimilar materials.
Can be welded in plane straight lines, arcs and arbitrary tracks.
Fast welding speed, smooth and beautiful weld seam, no need for treatment after welding or simple treatment, high weld quality, no air holes, precise control of positioning accuracy, small focus spot, so laser marking and laser in high-end bathroom stainless steel products Welding has a wide range of applications. For example, handles, faucets, stainless tableware, knives, etc. are mostly made by laser marking, and high-end electric kettles and the like are also sealed by laser welding.
Welding of butt welding of kitchen utensils and tableware, welding of butt welding of instruments, sensors, kitchen supplies and tableware, repair and modification of molds, mold making and use. Seamless welding of stainless steel cutlery, welding of instrument core connection.
Stainless Steel Metal Laser Welding Machine Specification
| Max Laser Power | 400w |
| Max Single Pulse Energy | 200J |
| Laser Wavelength | 1064nm |
| Laser Welding Frequency | ≤100Hz |
| Laser Welding Depth | 0.1~5.5mm |
| Pulse Width | 0.5~20ms |
| Focal Spot Diameter | 0.2-2mm |
| Output Light Path | 1~4 optional |
| Worktable Range | 300*200 optional |
| Positional System | Red light or CCD |
| Power Supply | 380V/60Hz |
| Cooling Type | Water Chiller |
| Worktable Travel | 200x200x200 |
Stainless Steel Metal Laser Welding Machine Features
1. Laser welding can achieve spot welding, butt welding, overlay welding, sealing welding, etc. for thin-walled materials and precision parts.
2. The laser power is large, the weld has a high aspect ratio, the heat affected area is small, the deformation is small, and the welding speed is fast.
3. The weld quality is high and flat, no porosity, and the toughness of the material after welding is at least equivalent to the parent material.
4. Humanized design, LCD display, centralized button operation is simpler.
5. Four-dimensional ball screw workbench adopts imported servo control system and optional rotary table. It can realize automatic welding such as spot welding, straight line welding and circumferential welding. It has wide application range, high precision and fast speed.
6. The current waveform can be adjusted arbitrarily, and different waveforms can be set according to different welding materials, so that the welding parameters and welding requirements are matched to achieve the best welding effect.
