| Name: | Mini Fiber Laser Marking Machine | Used Industry: | Home Decoration And Decoration |
|---|---|---|---|
| Applied Materials: | Aluminum Alloy Material | Laser Source: | Raycus Laser Source & IPG |
| Product Features: | Sunny Galvanometer | Service: | Can Customize |
| High Light: | small laser marking machine,small laser engraving machine |
||
Principle
Worktable surface can move up and down to adapt to different thickness of the workpiece, the workpiece surface is in the laser focal plane, the computer through a dedicated marking control software, you need to mark the text and graphics, set the size of text and drawings, the total Of the marking area, the laser beam walking speed and the need to repeat the number of scanning system can move under the control of the computer, the control laser beam marking the workpiece set the text and drawings, the software now has automatic image distortion Correction function, to achieve precision image marking.
Application:
Hardware equipment industry: tools, measuring tools, cutting tools, sanitary ware, tableware, locks, Daojian, medical equipment, fitness equipment, stainless steel products, etc
Laser Engraving Machine For Sale parameter
| type | Fiber laser marking machine |
| Size | 75*55*83cm |
| Gross Weight | 75kg |
| Laser power | 10/20/30/50 w |
| Laser wavelength | 1064nm |
| Power supply | 220V±10%/50Hz/4A |
| Repeating precision | ±0.002 |
| Repeating frequency | ±0.002 |
| Marking range | 110x110mm(customize) |
| Marking depth | 0.01~1mm |
| Marking speed | 7000mm/s |
| Minimum character | 0.15mm |
| Minimum line width | 0.01mm |
| Marking content |
Graphics, text, bar codes, two-dimensional code, date, batch number, serial number |
Usage method
1, double-click marking program icon, enter the program;
2, select the marking file, double-click the contents of the date, time to modify, click confirm, modify completed
Product features
Fine laser engraving, lines can reach millimeters and microns, the use of laser marking technology forged labels and make changes are very difficult, the product is important for security.
Service
In order to better ensure the normal operation of equipment, promptly answer the questions raised by users, help users to solve problems, maintain the center and all over the network, and take charge of the opening, maintenance and technical consultation services. Maintenance center by a full-time engineer is responsible for providing free technical advisory services to customers at any time.
FAQ
How to extend the service life? Prevent dust pollution.The power supply and the optical fiber access port of the laser head must be installed with the protective cover provided with the system in the state of not being connected with the optical fiber to prevent the external dust from polluting the internal optical components.
Design feature
Handheld portable fiber laser marking machine with maintenance-free features. Maintenance of the machine is one of the ways to make the machine work very well. The maintenance-free feature eliminates many unnecessary tasks for the customer, saves time and indirectly increases work efficiency.
Function
The all-fiber design of the laser ensures the high reliability of the laser without the need for any optical components for alignment adjustment.
After service
The equipment package is guaranteed to meet the requirements of moistureproof, rain proof, antirust, anticorrosion and shock proof, and the identification is clear and unmistakable, so that the articles are safely and promptly shipped to the site.
Packing and shipping
1.Standard export wooden case packing
Delivery Time:1~5 working days
| Delviery time | 7-15 working days |
| Type of shipping | Express,air or sea |
| Terms of payment | T/T,credit card,,paypal |
| package size | 75x55x83cm |
| Gross weight | 75KG |
