0.5MM Depth IPG Mini Laser Engraver Machine 7000MM Marking Speed For Metal

China 0.5MM Depth IPG Mini Laser Engraver Machine 7000MM Marking Speed For Metal supplier
0.5MM Depth IPG Mini Laser Engraver Machine 7000MM Marking Speed For Metal supplier 0.5MM Depth IPG Mini Laser Engraver Machine 7000MM Marking Speed For Metal supplier 0.5MM Depth IPG Mini Laser Engraver Machine 7000MM Marking Speed For Metal supplier 0.5MM Depth IPG Mini Laser Engraver Machine 7000MM Marking Speed For Metal supplier 0.5MM Depth IPG Mini Laser Engraver Machine 7000MM Marking Speed For Metal supplier

Large Image :  0.5MM Depth IPG Mini Laser Engraver Machine 7000MM Marking Speed For Metal

Product Details:

Place of Origin: China(mainland)
Brand Name: ZIXU
Certification: ISO,CE,FDA
Model Number: FLMM-B01

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: USD 4000-6500 per sets
Packaging Details: Packing in wooden case,75*55*83cm
Delivery Time: after payment 7-15 working days
Payment Terms: L/C,D/A,D/P,T/T,,MoneyGram,Paypal
Supply Ability: 500 sets per month
Contact Now
Detailed Product Description
Name: Mini Laser Engraver For Metal Applicable Material: Metal
Brand: Raycus Product Features: Laser Power:20w
Service: Can Customize Profit Model: OEM
High Light:

portable laser marking machine

,

small laser engraving machine



Marking 0.5Mm Depth IPG 7000Mm Marking Speed Mini Laser Engraver For Metal



Principle



Using the laser beam is used to mark a permanent mark on variety of surface



Application:



Especially suitable for food, medical packaging materials marking, and other applications.



0.5MM Depth IPG Mini Laser Engraver Machine 7000MM Marking Speed For Metal

0.5MM Depth IPG Mini Laser Engraver Machine 7000MM Marking Speed For Metal



Mini Laser Engraver For Metal parameter



type Fiber laser marking machine
Size 75*55*83cm
Gross Weight 75kg
Laser power 10/20/30/50 w
Laser wavelength 1064nm
Power supply 220V±10%/50Hz/4A
Repeating precision ±0.002
Repeating frequency ±0.002
Marking range 110x110mm(customize)
Marking depth 0.01~1mm
Marking speed 7000mm/s
Minimum character 0.15mm
Minimum line width 0.01mm
Marking content

Graphics, text, bar codes, two-dimensional code,

date, batch number, serial number





Usage method



The marking speed of laser marking machine is slowed down. The same power and other parameters only modify the speed of marking, and the depth of marking will be deeper.



Product features



It belongs to non - contact processing, no damage to products, no tool wear and good marking quality.





FAQ



What is the difference between fiber laser marking machine and CO2 laser marking machine? The fiber laser marking machine has high electro-optical conversion efficiency, and the whole machine can not consume 500W. It is the 1/10 of the lamp pumped solid-state laser marking machine, which greatly saves energy consumption. The processing speed is 2-3 times that of the traditional marking machine. The operation life of the laser is up to 100000 hours.
(2) CO2 laser marking machine: laser power is large, it can be applied to engraving and cutting various non-metallic products, and the laser runs for 20000-30000 hours.



Design feature



The laser beam is fine, the processing material consumption is very small, and the processing heat affected zone is small.





Function



Moreover, it has the characteristics of fast response speed, high marking speed (hundreds of characters per second, hundreds of characters), high quality of marking, good sealing performance of light path and strong adaptability to environment.



After service



Our company will regularly contact customers and ask whether the machine is used normally, as one of the routine maintenance works, that is, the company's organization will inquire once a year about the equipment run by the machine. The company inquired about the engineers and technicians, with the participation of the designers. And listen to the problems and suggestions reflected by the user maintenance personnel, and constantly improve the hardware and software functions and quality of the products.



Packing and shipping



we supply Express Service,more convenient



Delviery time 7-15 working days
Type of shipping Express,air or sea
Terms of payment T/T,credit card,,paypal
package size 75x55x83cm
Gross weight 75KG
