| Brand: | Sunny | Marking Material: | Metal |
|---|---|---|---|
| Marking Product: | Ring | Service: | Oem |
| Laser Type: | Uv Laser | Laser Power: | 5w |
| High Light: | uv laser engraving machine,uv laser marking systems |
||
More Than 10 Years Oem Experience Different Style Uv Marking Machine For Ring
Product introduction
Carbon dioxide laser marking machine is a gas laser machine, which produces a wavelength of 10.64um, belonging to the mid-infrared band, Co2 laser machine has a larger
Power and high electro-optical conversion efficiency. It uses Co2 gas as a working substance. The Co2 gas and other auxiliary gas into the discharge tube, when in
Glow discharge occurs in the discharge tube when the electrode is pressurized, so that the gas molecules to release the laser. The release of the laser energy amplification, the line into a laser beam.Through the computer-controlled galvanometer to change the laser beam path to achieve automatic marking.
|
Parameter
|
Parameter index
|
Unit
|
Illustration
|
|
Laser wavelength
|
354.7
|
nm
|
/
|
|
Average output power
|
3.0-5.0
|
W
|
@30kHz
|
|
pulse width
|
<20
|
ns
|
@30kHz
|
|
Pulse repetition frequency
|
10-100
|
KHz
|
/
|
|
Laser output mode
|
TEM00
|
/
|
/
|
|
Beam quality
|
<1.2
|
/
|
/
|
|
Spot diameter
|
0.8+-0.1
|
mm
|
Measured at window
|
|
Beam divergence angle
|
<1.2
|
mrad
|
/
|
|
Beam circularity
|
>90
|
/
|
/
|
|
Pulse stability
|
<3
|
%
|
RMS/@30kHz
|
|
Power stability
|
<5
|
%
|
RMS/8hr
|
|
Beam pointing stability
|
<30
|
urad/℃
|
/
|
|
Polarization degree
|
>100:1
|
/
|
/
|
|
Polarization direction
|
Horizontal
|
/
|
/
|
|
Working temperature and humidity
|
10to35 <80
|
℃ %
|
/
|
|
Storage temperature and humidity
|
-20 to 65 <90
|
℃ %
|
/
|
|
Power
|
100-240 50/60<500
|
VAC Hz W
|
Single phase
|
|
Warranty
|
15
|
months
|
/
|
Application
Used in electronic components, integrated circuits (IC), electrical appliances, mobile communications, metal products, tool accessories, precision instruments, glasses watches and clocks, jewelry accessories, auto parts, plastic buttons, building materials, PVC pipe.
1.using the rear focus, small size, high degree of integration, easy to move, to support a variety of venues
2, marking speed, high precision, marking accurate and clear, not easy to fade
3, a wide range of application materials, suitable for most non-metallic materials marking
FAQ
1.co2 laser marking machine laser what kind? 1. Imported metal tube 2. Domestic metal tube 3. Domestic glass tube,Our company is using foreign or domestic metal tube lasers, longer service life 2.co2 laser marking machine can mark what content? A variety of non-metallic materials and some metal products, such as bamboo products, wood, acrylic, leather, glass, building ceramics, rubber, etc. 3.co2 laser marking machine marking speed? Marking speed, up to 7000mm / s
Design feature
CO2 laser marking machine's main components are: CO2 laser, 10.64 field lens, 10.64 beam expander, CO2 laser power, scanning galvanometer, control computer, laser control card, laser control software, laser machine rack, lifting mobile platform , Circuit control system
Product features
1, equipment integration design, lightweight and beautiful.
2, air-cooled, no supplies, the use of low cost.
3, power controlled by software, power continuously adjustable.
4, marking clear, easy to wear. Carving depth of random control.
5, without any operating system restrictions, easy to operate, light closed, stable and reliable, maintenance-free.
6, Main functions and advantages: Perfect and reasonable machine design, perfect combination of control system and marking software make the life of product components greatly enhanced, long time running failure rate is low, the product performance is stable and reliable.
Chuke Factory
Packing in wooden case,95*81*122cm The machine gross is 1-188KG, you can use express delivery. If more than 75KG, you can choose sea transportation.
Packing and shipping
1 year guarantee,providing free technical support.
2.During the warranty period, Warranty period, the required parts after the non-human damage free replacement,the freight is borne by us.
3.Machine has been adjusted before delivery, operation instructions is included in the delivery. If there is any other questions, pls kindly tell us.
| Delviery time | 7-15 working days |
| Type of shipping | Express,air or sea |
| Terms of payment | T/T,credit card,,paypal |
| package size | 95x81x122cm |
| Gross weight | 188KG |
