Product Details:
Payment & Shipping Terms:
|
| Machine Struc Ture: | Portable | Feature: | Affordable |
|---|---|---|---|
| Marking Product: | Bottles | Marking Content: | Date |
| Laser Power: | 3w | ||
| High Light: | uv laser marker,uv laser engraving machine |
||
Affordable Glassware Surface Uv Printing Machine For Mini Bottles
Product introduction
UV laser marking machine is a series of laser marking machine, so the principle is the same with the laser marking machine, all with a laser beam on the surface of a variety of permanent marking. Marking effect is through the short wavelength laser directly interrupt the molecular chain (unlike long-wave laser generated by the evaporation of surface material to reveal the deep material) to show the desired pattern of etching, text.
|
Parameter
|
Parameter index
|
Unit
|
Illustration
|
|
Laser wavelength
|
354.7
|
nm
|
/
|
|
Average output power
|
3.0-5.0
|
W
|
@30kHz
|
|
pulse width
|
<20
|
ns
|
@30kHz
|
|
Pulse repetition frequency
|
10-100
|
KHz
|
/
|
|
Laser output mode
|
TEM00
|
/
|
/
|
|
Beam quality
|
<1.2
|
/
|
/
|
|
Spot diameter
|
0.8+-0.1
|
mm
|
Measured at window
|
|
Beam divergence angle
|
<1.2
|
mrad
|
/
|
|
Beam circularity
|
>90
|
/
|
/
|
|
Pulse stability
|
<3
|
%
|
RMS/@30kHz
|
|
Power stability
|
<5
|
%
|
RMS/8hr
|
|
Beam pointing stability
|
<30
|
urad/℃
|
/
|
|
Polarization degree
|
>100:1
|
/
|
/
|
|
Polarization direction
|
Horizontal
|
/
|
/
|
|
Working temperature and humidity
|
10to35 <80
|
℃ %
|
/
|
|
Storage temperature and humidity
|
-20 to 65 <90
|
℃ %
|
/
|
|
Power
|
100-240 50/60<500
|
VAC Hz W
|
Single phase
|
|
Warranty
|
15
|
months
|
/
|
Application
Mainly used for ultra-fine marking, engraving, especially suitable for food, pharmaceutical packaging material marking, drilling microporous, high-speed division of glass materials and silicon wafers for complex graphic cutting applications.
Laser beams typically provide low-voltage alternative methods for mechanical printed circuit board processing, such as milling or automatic circuit board cutting. But UV laser marking lasers do not have the benefits of other lasers, which can limit thermal stress. This is because most UV laser systems operate at low power.
FAQ
1. UV marking machine cleaning lenses need to pay attention to the problem? 1. The mirror surface directly touches the surface of the hard object; 2. The hand touches the mirror surface; 3. The non-lens tissue wipe or forcefully wipe the lens with the 3D dynamic scanning system; 4. When assembling the lens, Light path adjustment of the whole process; 5. On the mirror or gas air jet air injection Note: Laser lens wipe be careful.
Design feature
Laser designers have many years of laser development experience, technology accumulation is very mature. The laser uses a unique cavity design, the internal optical path using a locking mechanism, thus ensuring a good laser anti-attenuation and equipment shock resistance.
Product features
UV laser beam not only good quality, focusing spot smaller, ultra-fine marking can be achieved; UV laser marking machine in addition to copper, suitable for processing materials more widely.
Chuke Factory
Chongqing Chuke Intelligent Machinery &Equipment Co.,Ltd is a production and processing sales as one of the export enterprises, the company has the right to import and export business, specialized in the production and sale of marking products, the company has introduced foreign advanced manufacturing technology marks the industry combined with the actual situation Marking , dedicated to industrial manufacturing and processing a wide and comprehensive marking solutions, independent research and development and manufacturing all kinds of fiber laser marking machine, CO2 laser marking machine, side-pump laser marking machine, laser engraving machine, laser welding machine, pneumatic marking machine, electric marking machine portable marking machine, automobile and motorcycle with special marking machine, cutting plotter, manual plate embossing machines, electric corrosion marking machine, inkjet machine and marking machine spare parts, etc.Companies own brand --ZI XU, has a large range of laser marking products, marking one scale industry reputation. The company has import and export operation rights, Beibei District of Chongqing Municipality export enterprises.
After sale service
1 year guarantee,providing free technical support.
2.During the warranty period, the required parts after the non-human damage free replacement,the freight is borne by us.
3.Machine has been adjusted before delivery, operation instructions is included in the delivery. If there is any other questions, pls kindly tell us.
Packing and shipping
Packing in wooden case,95*81*122cm The machine gross is 1-188KG, you can use express delivery. If more than 75KG, you can choose sea transportation.
| Delviery time | 7-15 working days |
| Type of shipping | Express,air or sea |
| Terms of payment | T/T,credit card,,paypal |
| package size | 95x81x122cm |
| Gross weight | 188KG |
Contact Person: zoya zhou
